PF시리즈,폴리에스터박변형게이지
폴리에스테르박변형게이지PF시리즈는폴리에스테르수지를기반으로한박게이지입니다. 강재나 콘크리트, 모르타르에 사용합니다.
| Applicable specimen | Metal, Mortar |
| Operational temperature(℃) | -20 to +80 ℃ |
| Temperature compensation range(℃) | +10 to +80 ℃ |
| Applicable adhesive | CN-E, RP-2, PS |
| Backing | Polyester |
| Element | Cu-Ni |
| Strain limit at room temperature | 2 % (20000 x 10-6 strain) |
| Fatigue life at room temperature | 1 x 106 (±1500 x 10-6 strain) |
Gauge pattern |
Type | Gauge | Gauge | Backing | Backing | Resistance |
| length | width | length | width | (Ω) | ||
| (mm) | (mm) | (mm) | (mm) | |||
| PFL-10-11 | 10 | 0.9 | 17.5 | 5 | 120 | |
| PFL-20-11 | 20 | 1.2 | 28 | 6 | 120 | |
| PFL-30-11 | 30 | 2.3 | 40 | 7 | 120 | |
2-element |
PFLC-20-11 | 20 | 1.2 | 28 | 28 | 120 |
| PFLC-30-11 | 30 | 2.3 | 40 | 40 | 120 | |
3-element |
PFLR-20-11 | 20 | 1.2 | 28 | 28 | 120 |
| PFLR-30-11 | 30 | 2.3 | 40 | 40 | 120 |
Each package contains 10 strain gauges.
| Application | Product name | Lead wire code | Operating temperature (℃) | Leadwire code exampled |
| General use (temperature unchanged during measurement) | Paralleled vinyl | LJB-F | -20 to +80 | PFL-10-11-3LJB-F |
| Paralleled vinyl | LJC-F | PFL-10-11-3LJC-F | ||
| General use | 3-wire paralleled vinyl | LJBT-F | -20 to +80 | PFL-10-11-3LJBT-F |
| 3-wire paralleled vinyl | LJCT-F | PFL-10-11-3LJCT-F | ||
| 1-gauge 4-wire system | Polypropylene 4-wire parallel wire | LQM-F | -20 to +100 | PFL-10-11-3LQM-F |
| (with modular) |
* PFLC-20-11, PFLR-20-11, PFLC-30-11, and PFLR-30-11 cannot be additionally outfitted with a lead wire
* Only the leadwires using lead-free solder are available for strain gauges with CE marking.
| Type | Gauge | Gauge | Backing | Backing | Resistance | Lead wire | Type name |
| length | width | length | width | (Ω) | pre-attached | of lead wire | |
| (mm) | (mm) | (mm) | (mm) | preattached | |||
| PFL-10-11 | 10 | 0.9 | 17.5 | 5 | 120 | Paralleled 1m | -1LJC-F |
| Paralleled 3m | -3LJC-F | ||||||
| Paralleled 5m | -5LJC-F | ||||||
| 3-wire 3m | -3LJCT-F | ||||||
| 3-wire 5m | -5LJCT-F | ||||||
| PFL-20-11 | 20 | 1.2 | 28 | 6 | 120 | Paralleled 1m | -1LJC-F |
| Paralleled 3m | -3LJC-F | ||||||
| Paralleled 5m | -5LJC-F | ||||||
| 3-wire 3m | -3LJCT-F | ||||||
| 3-wire 5m | -5LJCT-F | ||||||
| PFL-30-11 | 30 | 2.3 | 40 | 7 | 120 | Paralleled 1m | -1LJC-F |
| Paralleled 3m | -3LJC-F | ||||||
| Paralleled 5m | -5LJC-F | ||||||
| 3-wire 3m | -3LJCT-F | ||||||
| 3-wire 5m | -5LJCT-F |
* Minimum order quantity is 10 gauges.
* PFLC-20-11, PFLR-20-11, PFLC-30-11, and PFLR-30-11 cannot be additionally outfitted with a lead wire
