TML 스트레인게이지, 복합재료 UBF



UBF 시리즈 복합 재료용 소형 변형 게이지



복합 재료를 대상으로 개발한 변형 게이지로, 피측정물에 대한 구속 효과를 줄이기 위해 당사의 독자적인 특수 그리드 형상을 가진 변형 게이지입니다. 부드러운 게이지 베이스의 개발로 열사이클에 있어서 반복 횟수나 게이지 크리프 특성이 종래형 변형 게이지와 비교하여 크게 향상되었습니다(당사비). 또한 옵션(-F)으로 무연 땜납 사양에도 대응 가능합니다.



Applicable specimen	Fiber Reinforced Plastics(FRP)
Operational temperature	Static:-30 to +120 Ω
	Dynamic:-30 to +150 Ω
Temperature compensation range	-
Temperature compensation range	EB-2, CN, NP-50B
Backing	Polyimide-Amide
Element	Cu-Ni
Strain limit	3% (30000 x 10-6 strain)
Fatigue life at room temperature	1×106 (±1500 x 10-6 strain)









Gauge patternTypeGaugelength(mm)Gaugewidth(mm)Backinglength(mm)Backingwidth(mm)Resistance(Ω)

	UBFLA-03	0.3	1.9	3.4	2.5	120
	UBFLA-1	1	1.3	4.5	2	120





PurposeLead wiresLead wire symbolOperating temperature range(℃ )Gauge type exampled

General measurement (no temperature change)	2-wire parallel vinyl wire	LJB-F	－20 to +80	UBFLA-1-3LJB
	2-strand twisted vinyl wire	LH		UBFLA-1-3LH
General measurement	3-wire parallel vinyl wire	LJBT/LJBT-F	－20 to +80	UBFLA-1-3LJBT
	3-strand twisted vinyl wire (3-wire system)	LHT		UBFLA-1-3LHT
Medium/high temperature	3-wire parallel special vinyl wire	LXT/LXT-F	－20 to +150	UBFLA-1-3LXT
	3-strand twisted FEP single-core wire	6FB♦LT	－269 to +200	UBFLA-1-6FB3LT
