TML 스트레인게이지, 리드선,

변형 게이지 전용 리드선

일반 응력 측정에서는 생력화를 위해 대부분 리드선이 있는 변형 게이지가 사용됩니다. 변형 게이지는 고객의 요구에 부응하기 위해 수많은 리드선 변형 게이지를 준비했습니다. 변형 게이지의 대부분의 제품에는 요청하신 리드선을 접속할 수 있습니다. 리드선 연결을 원하실 때는 부담없이 당사에 상담해 주십시오.





·극세 비닐선
비닐선 중에서도 특히 피복을 얇게 하고 가는 심선을 사용하여 외경이 0.4mm입니다. 좁은 장소의 배선 등에 사용됩니다. 심선에 의해 선을 사용하여 유연하며, 반복적인 굽힘을 받아도 단선이 잘 되지 않습니다.

·실드 달린 비닐선
3개보다 선 비닐 선에 쉴드를 입힌 리드선으로 노이즈를 차폐하는 리드선입니다.



Leadwire type (Suffix code of leadwire)	Core/diameter (cross section area)	Applicable temperature (℃)	Total resistance of leadwire (Ω)	Outside sheath dimensions (mm)	Length per roll*1 (m)	Colors
paralleled vinyl leadwire	7/0.12	-20 to +80	0.44	1.1 x 2.2	200*2	Red-White, Red, Green, Black, White, Yellow, Blue
(LJB/LJB-F*4)	(0.08mm2)
3-wire paralleled vinyl leadwire				1.1 x 3.3		White, One wire with Blue, Red, or Orange stripe *3
(LJBT/LJBT-F*4)
paralleled vinyl lead wire	10/0.12	-20 to +80	0.32	1.4 x 2.8	200	Grey
(LJC/LJC-F*4)	(0.11mm2)
3-wire paralleled vinyl leadwire				1.4 x 4.2	100	Grey, One wire with Blue stripe*3
(LJCT/LJCT-F*4)
paralleled vinyl leadwire	12/0.18	-20 to +80	0.12	1.9 x 3.8	200	Grey
(LJD)	(0.3mm2)
3-wire paralleled vinyl leadwire				1.9 x 5.7	100	White, One wire with Red stripe*3
(LJDT)
twisted vinyl leadwire	5/0.07	-20 to +80	1.8	Φ0.8	-	Red, Green, White
(LH)	(0.02mm2)
3-wire twisted vinyl leadwire				Φ1.0		Red, Green, White
(LHT)
3.2mm-dia. 2-core shielded vinyl leadwire	7/0.12	-20 to +80	0.44	Φ3.2	200	Outer : White
(LS)	(0.08mm2)					Core wire : Green-Green
3mm-dia. 3-core shielded vinyl leadwire	7/0.12	-20 to +80	0.44	Φ3.0	200	Outer : Red, White or Green
(LTSA/LTSA-F*4)	(0.08mm2)					Core wire : Red-Black-White
5mm-dia. 3-core shielded vinyl leadwire	7/0.26	-20 to +80	0.1	Φ5.0	200	Outer : Black
(LTSB/LTSB-F*4)	(0.3mm2)					Core wire : Red-Black-White
polypropylene 4-wire paralleled leadwire	7/0.12	-20 to +100	0.44	0.9 x 4.0	200	White, One wire with Red, Black, or Blue stripe *3
(LQM/LQM-F*4)	(0.08mm2)
3-wire paralleled special vinyl leadwire	7/0.12	-20 to +150	0.44	0.9 x 2.7	200	Red-Black-White
(LXT/LXT-F*4)	(0.08mm2)



※ 1 : 판매단위
※ 2 : ○ 라인 ... 독립선을 나타내는 리드선의 라인 색상입니다.
※ 3 : 옵션 - F 무연납땜시 리드선입니다.



·폴리우레탄선
납땜 인두 등으로 피막을 박리할 수 있으므로 후가공이 가능합니다. 반면, 피막이 약하기 때문에 취급에 주의가 필요합니다.

·폴리에스테르 선
폴리우레탄 선에 비해 피막재에 강도가 있기 때문에, 피막의 박리에는 전용 박리제가 필요합니다.
(인두로 피막의 박리는 불가능합니다.)

·폴리이미드선
폴리에스테르선에비해더욱피막제를강하게한리드선입니다. (인두로 피막의 박리는 불가능합니다.)



Leadwire type (Suffix code of leadwire)	Core/diameter (cross section area)*1	Applicable temperature (℃)	Total resistance of leadwire (Ω)	Outside sheath dimensions (mm)	Length per roll (m)	Colors
Polyurethane leadwire*2	1/0.14	-10 to +120	2.5	Φ0.16	-	Red, Brown, Green
(LP/LP-F*3)	1/0.18		1.5	Φ0.20
Polyester leadwire*2	1/0.14	-196 to +200	2.5	Φ0.16	-	Brown
(LU/LU-F*3)	1/0.18		1.5	Φ0.20
Polyimide leadwire	1/0.14	-269 to +300	2.5	Φ0.16	-	Brown
(LE/LE-F*3)	1/0.18		1.5	Φ0.20



※ 1: 각 에나멜선 모두 φ0.14와 φ0.18 2종류가 준비되어 있습니다.
※ 2: 적층형 2축, 3축 게이지에는 리드 포함 가공이 불가능합니다.
※ 3 : 옵션 - F 무연납땜시 리드선입니다.



Leadwire type (Suffix code of leadwire)	Core/diameter (cross section area)	Applicable temperature (℃)	Total resistance of lead wire per meter (Ω)	Outside sheath dimensions (mm)	Length per roll*1 (m)	Colors
2-wire twisted cross-linked vinyl sheathed leadwire	7/0.16	-20 to +100	0.24	Φ3.0	-	White
(LJRA)	(0.14mm2)
3-wire twisted cross-linked vinyl sheathed leadwire	7/0.127		0.4	Φ2.0	200	Red-Green-Black
(LJRTA)	(0.09mm2)



Leadwire type (Suffix code of leadwire)	Core/diameter (cross section area)	Applicable temperature (℃)	Total resistance of lead wire per meter (Ω)	Outside sheath dimensions (mm)	Length per roll*1 (m)	Colors
3-wire twisted cross-linked polyethylene sheathed leadwire	7/0.127	-65 to +125	0.4	Φ2.0	-	Red-Yellow-Black
(LJQTA/LJQTA-F*2)	(0.09mm2)					Red-Yellow-Blue
						Red-Yellow-White



Leadwire type (Suffix code of leadwire)Core/diameter (cross section area)Applicable temperature (℃)Total resistance of lead wire per meter (Ω)Outside sheath dimensions (mm)Length per roll*1 (m)Colors

3-wire twisted fluorinated resin (FEP) insulated leadwire (6FA_LT/6FA_LT-F*6)*4	7/0.18 (0.18mm2)	-269 to +200	0.2	Φ2.0	100	Red-Green-Blue
3-wire twisted fluorinated resin (FEP) insulated leadwire*5 (6FAS_LT/6FAS_LT-F*6)*4 (Surface treatment(tetraetching) is not required)	7/0.18 (0.18mm2)		0.2	Φ2.0	100	Red-Green-Blue
3-wire twisted fluorinated resin (FEP) insulated leadwire (6FCS_LT/6FCS_LT-F*6)*4 (Surface treatment(tetraetching) is not required)	7/0.08 (0.04mm2)		1.1	Φ1.0	-	Red-Black-White
3-wire twisted fluorinated resin (FEP) insulated leadwire (6FB_LT/6FB_LT-F*6)*4	1/0.2		1.2	Φ1.1	-	Red-Green-Blue
3-wire twisted fluorinated resin (FEP) insulated leadwire (6FC_LT/6FC_LT-F*6)*4	7/0.08 (0.04mm2)	-269 to +200	1.1	Φ1.0	-	Red-Black-White
3-wire twisted fluorinated resin (FEP) insulated leadwire (6FD_LTS)*4	7/0.08 (0.04mm2)	-269 to +200	1.1	Φ1.5	-	Red (Red-Black-White)
3-wire twisted fluorinated resin (PTFE) insulated leadwire (4FA_LT / 4FA_LT-F*6)*4	7/0.16 (0.14mm2)	-269 to +260*3	0.24	Φ1.9	100	Red-Black-White
3-wire twisted fluorinated resin (PTFE) insulated leadwire (4FB_LT/4FB_LT-F*6)*4	1/0.2		1.05	Φ1.1	-	Red-Black-White



*1: Leadwires are supplied by one roll each.
*2: _ is filled with the lead wire length in meter
*3: PTFE leadwire is available for use in 300°C for a short term
*4: Suffix code LT(CT) means connecting terminal joint, while LT(TA) means insulation with film
*5: for easy application of coating: Surface treatment (tetra-etching) is not required when applying coating
*6: Lead-free solder is used for leadwires with option code "–F".



Leadwire type (Suffix code of leadwire)	Core/diameter (cross section area)	Applicable temperature (℃)	Total resistance of lead wire per meter (Ω)	Outside sheath dimensions (mm)	Length per roll (m)	Colors
Temperature-integrated 3-wire paralleled vinyl lead iwre	7/0.12	-20 to +80	0.44*1	1.2 x 3.6	-	Red-White-Blue
(TLJBT/TLJBT-F*3)	(0.08mm2)
Temperature-integrated 3-wire twisted fluorinated resin (FEP) leadwire	1/0.2	-269 to +200	1.2*1	Φ1.1	-	Red-White-Blue
(6FB_TLT/6FB_TLT-F*3)*2
