TML 스트레인게이지, 코팅제

SFDS

코팅제 일람인덱스



변형 게이지 사용 환경마다 요구되는 코팅제의 종류와 시공 방법은 다릅니다. 한 종류의 코팅제로 작동하지 않는 경우에는 여러 코팅제의 조합으로 변형 게이지를 보호합니다.
당사에서는 변형게이지 표면에 직접 도포되는 코팅층을 1차, 순서대로 2차, 3차 코팅이라 호칭하며 다층 코팅에 의한 변형게이지 보호를 권장하고 있습니다.
※ SDS(안전 데이터 시트) : 처음 본 제품을 사용하는 경우에는, 사용 전에 반드시 SDS를 요청하신 후에 잘 읽어 보시기 바랍니다.
산, 알칼리, 알코올 등의 특수 매체 내 코팅에 대해서는 당사에 문의해 주십시오.



Type	Type of coating materials	Operating temperature	Curing conditions	Materials	Contents
W-1	Hotmelt	0 to +50℃	Hot melting +100 to 120℃, hardening in room temperature	Microcrystalline wax solid	Single 500g
N-1	Rubber type solvent	-30 to＋80	Air-drying, a half day in room temperature	Special rubber based solvent thinned	25ｇ
K-1	Rubber type solvent	-269 to +60℃	Air-drying, a half day in room temperature	Special rubber based solvent thinned	25g *
UE-1	Rubber type solvent	-40 to +150℃	Air-drying, a half day in room temperature	Special rubber based solvent thinned	25g *
SB tape	Rubber type pressure sensitive	-30 to +80℃	Pressure sensitive	Butyl rubber	10mm (wide) × 3mm (thick) 5m long/roll
VM tape	Rubber type pressure sensitive	-20 to +80℃	Pressure sensitive	Butyl rubber	38mm (wide) × 0.635mm (thick) 6m long/roll
KE-348W(White)	Silicon	-50 to +200℃	Air-drying solvent-thinned a half day in room temperature	Silicon rubber	100g
KE-348T(Transparent)
TSE3976-B	Silicon	-50 to +250℃	Air-drying solvent-thinned a half day in room temperature	Silicon rubber	100g
