TML 스트레인게이지, 소성형 YHF

YHF 시리즈 소성역 변형 게이지



소성역 변형 게이지 YHF 시리즈는 실온에서 변형 한계가 30~40%인 초대 변형 측정용 변형 게이지입니다. 탄성 영역 및 큰 변형의 반복 측정에는 사용할 수 없습니다.
※ 접착 후, 장시간 (수일 이상) 방치 후 측정되는 경우의 접착제는 CN-Y를 권장합니다.
　CN-Y로 접착한 경우 1년 후에도 대왜곡 측정이 가능합니다. (시험체를 실내에 상온 보관한 경우)



Applicable specimen	Metal
Operational temperature (℃)	-30 to +80 ℃
Temperature compensation range (℃)	-
Applicable adhesive	CN, CN-Y
Backing	Special plastics
Element	Special alloy
Strain limit	30 to 40 %(300000 to 400000x10-6  strain)
Fatigue life at room temperature	2x104(±1500x10-6  strain)



Gauge pattern	Type	Gauge	Gauge	Backing length (mm)	Backing width (mm)	Resistance (Ω)
		length	width
		(mm)	(mm)
	YHFLA-2	2	1.5	8	2.7	120
	YHFLA-5	5	1.7	11	3	120



Application	Product name	Lead wire code	Operational temperature range	Leadwire code
				exampled
General use (temperature unchanged during measurement)	Paralleled vinyl	LJC-F	-20 to +80 ℃	YHFLA-5-3LJC-F
General use	3-wire paralleled vinyl	LJCT-F	-20 to +80 ℃	YHFLA-5-3LJCT-F
