TML 스트레인게이지, 용접형 AWM-8 시리즈





AWM-8



AWM은 1게이지법 3선식의 수감부가 완전 밀폐된 구조로 정적, 동적 변형 측정 + 300℃까지 사용할 수 있습니다. 게이지 베이스 재료에는 인코넬 600과 SUS304가 준비되어 있으므로 설치 대상 재료에 맞게 선택해 주십시오



Main object material	Metal
Operational temperature	-196 to +300℃
Temperature compensation range	RT to +300℃
Bonding adhesive	Spot welding (TML spot welder W-50R is required)
Backing	Inconel 600, SUS304
Element	Special alloy
Strain limit	1% (10000 x 10-6 strain)
Fatigue life at room temperature	1×106 (±1000×10-6 strain)







Type	Gauge	Gauge base		Test specimen	Resistance in (Ω)
	length
	(mm)	Dimensions	Materials
		(mm)
AWM-8-1A-2-11.0	8	L16 x W5 x T0.7	Inconel 600	Mild steel	120
AWM-8-1B-2-17.0			SUS304	Stainless



Each package contains one strain gauge.
Other cable length available on request
(Made to order by every 1 m for MI cable and by every 0.5 m for vinyl cable)
